HARDWARE FEATURES
Interface	1 10/100Mbps Auto-Sensing RJ45 Port (Auto MDI/MDIX, PoE) 1 External Reverse SMA Connector 1 Grounding Terminal
Button	Reset Button
External Power Supply	12VDC / 1.0A
Wireless Standards	IEEE 802.11a , IEEE 802.11n
Antenna	15dBi Dual-Polarized Directional Antenna
Dimensions ( W x D x H )	9.8 x 3.3 x 2.4 in. (250 x 85 x 60.5mm)
Antenna Beamwidth	Horizontal: 60° Vertical: 14°
Protection	15KV ESD Protection 4000V Lightning Protection Grounding Terminal Integrated

WIRELESS FEATURES
Frequency	5.180-5.240GHz 5.745-5.825GHz Note: It varies in different countries or regions.
Signal Rate	11a: Up to 54Mbps (Dynamic) 11n: Up to 150Mbps (Dynamic)
Reception Sensitivity	802.11a 54M: -77dBm 48M: -79dBm 36M: -83dBm 24M: -86dBm 18M:-91dBm 12M:-92dBm 9M:-93dBm 6M:-94dBm 802.11n 150M: -73dBm 121.5M: -76dBm 108M: -77dBm 81M: -81dBm 54M:-84dBm 40.5M:-88dBm 27M:-91dBm 13.5M:-93dBm
Wireless Modes	AP Router Mode AP Client Router Mode (WISP Client) AP / Client / Bridge / Repeater Mode
Wireless Functions	WDS Bridge, Wireless Statistics
Wireless Security	SSID Enable/Disable MAC Address Filter 64/128/152-bit WEP Encryption WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption
Advanced Functions	Up to 60 meters PoE is supported Provides 4-level signal LED indicator

OTHERS
Certification	CE, FCC, RoHS
Package Contents	TL-WA7510N Power Supply Unit Power Injector Resource CD Quick Installation Guide
System Requirements	Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC OS, NetWare, UNIX or Linux.
Environment	Operating Temperature: -30°C~70°C (-22℉~158℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing
